How to Shrink Volume in Windows Server 2022/2025

by John, Updated on: July 11, 2026

Certain OEM servers are configured with only the C drive on the primary system disk. In such scenarios, shrinking the volume to create at least one additional partition for applications is highly recommended to avoid cluttering the core operating system files. Likewise, if a data storage drive contains an oversized volume, it can be shrunk to organize different file types into distinct partitions. To shrink volumes in Windows Server 2022/2025, you can utilize native Windows utilities or specialized third-party software. This article provides a comprehensive guide detailing how to safely reduce partition sizes using both methods.

Shrink volume Server 2022

1. Shrink Volumes in Server 2022/2025 Using Native Utilities

Windows Server 2022/2025 provides two native utilities to assist with shrinking storage volumes. The Disk Management snap-in includes a "Shrink Volume" function with a Graphical User Interface (GUI), while the DiskPart tool operates via the command-line prompt. Although these utilities function differently, they share the exact same limitations when shrinking volumes in a Windows Server environment:

  1. They cannot shrink partitions formatted with the FAT32 or ReFS file systems; only NTFS is supported.
  2. They can only shrink a partition from right to left, generating the resulting unallocated space strictly on its right side.
  3. They cannot relocate unmovable system files, meaning they may fail to shrink a partition significantly even when a large amount of free space is available.

How to shrink a volume in Windows Server 2022/2025 via Disk Management:

  1. Press the Windows key + X simultaneously on your keyboard and select Disk Management from the menu.
  2. Right-click the target NTFS partition and select "Shrink Volume".
  3. The maximum available shrink space is calculated by default; you can input a smaller value if desired, and then click "Shrink".

How to shrink a volume in Windows Server 2022/2025 using the DiskPart command line:

  1. Press the Windows key + R to open the Run dialog box, type DiskPart, and press Enter.
  2. Type list volume and press Enter within the command-line window to view all available partitions.
  3. Type select volume X and press Enter (where X represents the specific number or drive letter of the partition to be shrunk).
  4. Type shrink desired=XX and press Enter (where XX specifies the target shrink amount in megabytes).

As previously explained, both native Windows utilities enforce strict operational limitations when reducing partition sizes. To overcome these restrictions seamlessly and optimize your storage layout, professional third-party software remains the ideal choice.

2. Shrink Partitions in Server 2022/2025 with Dedicated Software

Compared to native Windows utilities, NIUBI Partition Editor offers distinct architectural advantages when shrinking partitions in Windows Server 2022/2025 and legacy environments:

  1. It provides full compatibility for resizing both NTFS and FAT32 file systems, eliminating native tool restrictions on FAT32 modification.
  2. It automatically relocates "unmovable" system files during the process, allowing you to shrink partitions to their absolute minimum footprint.
  3. It gives you the flexibility to generate newly reclaimed unallocated space on either the left or right side of the modified volume, greatly simplifying subsequent extension operations.

How to shrink a volume in Windows Server 2022/2025 without data loss:

  1. Download and launch NIUBI Partition Editor, right-click any NTFS or FAT32 partition, and select "Resize/Move Volume".
  2. Within the pop-up window, drag either border toward the center to shrink the partition and generate unallocated space.
  3. Click "Apply" in the top-left corner of the dashboard to execute the pending volume modifications safely.

Watch the video tutorial below for a comprehensive visual demonstration of how to shrink and extend partitions in Windows Server 2022/2025:

Extend C drive

Prioritizing absolute data safety, NIUBI Partition Editor integrates 1-Second Rollback, Hot-Clone, Virtual Mode, and Cancel-at-will technologies to safeguard server system and data integrity. Beyond shrinking volumes and resizing partitions in Windows Server 2022/2025 and legacy editions from Server 2003 to 2019, NIUBI Partition Editor provides a comprehensive toolkit to merge, move, clone, convert, hide, and wipe partitions, as well as optimize file systems and scan for bad sectors.
