C drive low disk space is the most common issue on both Windows PC and server. When it happens, it costs such a long time to back up everything and restore, or reinstall Operating System and all programs. The best way is increasing C drive free space without losing data. In this article, I'll introduce how to increase C drive space in Windows PC/Server with native tool and best partition software.
Applies to: Windows 11, Windows 10, Windows 8, Windows 7, Windows Vista, Windows XP, Windows Server 2022, Windows Server 2019, Windows Server 2016, Windows Server 2012 (R2), Small Business Server 2011, Windows Server 2008 (R2) and Windows Server 2003 (R2).
Which tool to increase C drive free space
There are two native tools to help change partition size - Disk Management and diskpart. Diskpart is command prompt tool which can be used to shrink and extend partition in all Windows versions. Disk Management in Windows 7 and subsequent versions have "Shrink Volume" and "Extend Volume" functions with graphical interface.
Disk Management and diskpart work in different way, but they have same restrictions, they can only help you under specific condition. To increase system C drive space, there must be another partition behind it on the same disk. In addition, the right contiguous partition must be Primary partition. Before extending C drive, you must delete this contiguous partition. (learn more)
With third party software, there are no such restrictions, and it is much easier to resize partitions. There are many software in the market, the GUI and functions are all similar, but it doesn't mean any one is okay.
Different with read-only program, to decrease and increase partition size, all partition software will modify the parameters of associated disk, partition and files in MBR, DBR and other place. So there is risk of system damage and/or data loss while repartitioning hard disk.
Better than other software, NIUBI Partition Editor has unique 1-Second Rollback, Cancel-at-well and Virtual Mode technologies to protect system and data. Because of the advanced file-moving algorithm, it is much faster. To increase C: drive space in Windows 11/10/8/7/Vista/XP (32 & 64 bit), NIUBI has free edition for home computer users.
Increase C drive free space without any software
If you can delete the right contiguous partition (D:) and D is a Primary partition, you can expand C drive without any 3rd-party software. (Caution: do not delete this partition if you installed programs in it.)
How to increase C: drive space with Disk Management:
- Transfer all files in the right contiguous partition (D:) to other place.
- Press Windows and R on keyboard, type diskmgmt.msc and press Enter to open Disk Management.
- Right click D drive and select Delete Volume.
- Right click system partition C and select Extend Volume.
- Extend Volume Wizard window will pop up, click Next to continue.
- Available disk and space is selected by default, click Next to continue.
- Click Finish to confirm and proceed the extending operation.
If you want to extend C drive with diskpart command, follow the steps.
Increase C drive space with free partition software
With NIUBI Partition Editor, you can increase C drive free space without deleting other partition. To accomplish this task, you just need to drag and drop on the disk map. Follow the steps below to shrink partition and transfer space to C drive.
How to increase C drive space in Windows 11/10/8/7 without losing data:
- Download NIUBI Partition Editor, right click drive D: and select "Resize/Move Volume", drag left border towards right in the pop-up window, or enter an amount in the box of "Unallocated space before". Then Unallocated space will be generated on the left side of D.
- Right click C: drive and select "Resize/Move Volume" again, drag right border towards right in the pop-up window to combine Unallocated space.
- Click Apply on top left to execute. (Otherwise, the changes won't take effect)
If you want to shrink the non-adjacent drive E on the same disk, there's an addition step to move Unallocated space behind C drive.
- No software can add space to C drive from another separate disk, if there's no available free space on the same disk, follow the steps to clone system disk to a larger one and expand C drive with extra disk space.
- If you use any types of hardware RAID array such as RAID 0/1/5, do not break RAID array, follow the same steps above.
The steps to increase C drive space in Windows Server 2022/2019/2016/2012/2008/2003 are the same but you need the server or higher edition.
Increase C drive size for RAID/VMware/Hyper-V VM
If you want to increase C drive space for virtual disk in VMware/Hyper-V/Virtualbox, it is similar. Firstly, check if there's enough free space in other virtual partition on the same disk. If yes, simply follow the steps above.
If there's not enough free space on the same virtual disk, you can expand this virtual disk without copying to another one.
After expanding disk, additional space will be shown as Unallocated at the end of disk. Follow the steps in the video to move and add Unallocated space to C drive. Besides shrinking, moving and extending partitions, NIUBI Partition Editor helps you do many other disk partition management operations.
